29er mtb 24mm internal width 20mm deep asymmetric carbon rim

Item XC924X, weight 295g, ERD 595mm. New lightest 29er mtb rim for Cross-Country riders, with 295g a piece, the complete wheelset can come in at a surprisingly low weight of around 1,100g. Perfect for race days with the super climbing-friendly lightweight, and for backwood adventures with enhanced strength.
  • Item No.:

    XC924X
  • Size:

    29 inch
  • Material:

    full carbon Toray T700 & T800
  • Type:

    hookless (tubeless ready)
  • Weight:

    295g±15
  • ERD:

    605mm
  • Inner width:

    24mm
  • Outer width:

    30mm
  • Depth:

    20mm
  • Max spoke tension:

    140kgf
  • Max weight limit:

    90kg / 198lbs
  • description

Product Item: 29er mtb 24mm internal width 20mm deep asymmetric carbon rim


New lightest 29er mtb rim for Cross-Country riders, with 295g a piece, the complete wheelset can come in at a surprisingly low weight of around 1,100g. Perfect for race days with the super climbing-friendly lightweight, and for backwood adventures with enhanced strength.


Rim Specs


 Rim Model  XC924X
 Material  Toray T700 & T800 premium carbon fiber
 Size  29"
 Intended Use  Cross Country
 Bead Type  Hookless
 Tubeless Ready  Yes
 Inner/Outer Width  24mm/30mm
 Depth  20mm
 ERD  605mm (including nipple head dimension)
 Rim Weight  295g±15
 Offset  3mm (asymmetric)
 Max Cyclist Weight (on flat ground)  90kgs / 198lbs
 Rim Weave  UD, 3k, 3k twill, 6k, Marble
 Rim Finish  Matte, Glossy
 Spoke Hole Angel  ±7°
 Spoke Hole Diameter
 2.5mm, 4.5mm or customized
 Access Hole Diameter  8.5mm
 Valve Hole Diameter  6.5mm
 Spoke Tension 110~130kgf (recommended)
 Max Tire Pressure  60psi /4.14bar (recommended max)
 Recommended Tire Width  2.0" ~ 2.4"
 Decal / Paint  None or Custom graphics
 Warranty  5 years


All carbon rims are 100% customizable at Carbonal bike. If your preferred specs are not listed, feel free to contact us (sales@carbonalbike.com) with your special requirements described, we will do our best to help you.



Features:

  • The asymmetric structure of the rim allows a more even spoke tension which further increases the rigidity of a complete impeller.
  • Impact Resistant Construction. Carbon rims feature a layer of composite material that increases the impact strength and helps distribute energy and shock from impacts to the rim.
  • Super lightweight, rim constructed with premium Toray T700 & T800 carbon fiber, best strength to weight ratio with no expense spared.
  • Smooth Wall Tec. No folded prepreg during curing, smooth both inside and outside rim wall to reduce potential quality issues.
  • Carbon Strip Reinforcement. Use unique carbon strip to strengthen the spoke tension and stabilize rim structure and reduce the rim weight.
  • Hookless Rim Bead. Hookless rim bead more straight and smooth side walls, tire can touch rim walls fully. More durable and impact resistance compared to the traditional hooks rim.
  • Tubeless Ready. Beadlock design makes the rims better tubeless tire setup and better sealing, results a more lightweight carbon wheels.
  • Angled spoke holes allows the nipple to pull straight in line with the spoke for reduced stress, this results in fewer broken spokes and nipples.

Manufacturing process:

Our Engineering team creates a unique fiber orientation which amplifies the desired riding characteristics for a given rim. And each rim carries its own layup schedule documents which are meticulously by the layup workers, it ensures the accuracy of each rim in the production process.


Carbon rims are made in one piece molding, each rim is made by one piece long carbon fiber, no wrinkles, to make the stength of rim is the stongest. And we use a unique process to remove the air bladder from the valve hole, so that the rim does not have to be patched like traditional manufacturers use.


Warranty Policy:

5 years warranty and 2 years crash replacement;

1.3 million liability insurance worldwide, included commercial general liability and occurrence basis.


More information about our Warranty Policy.


100% Quality Inspection:

Carbonal does 100% quality inspection and record in database, each carbon rim is given a unique ID number, which allow us to deliver the highest quality product possible and track every rim to ensure the best after-sale service.


Read more about Carbonal carbon rim Quality Control.
